CAT 313

Name: CAT 313
Brand: CAT
SKU: 007372FA
Price: 16820 USD
Availability: InStock

Hind km-ta

Lemmik

Jaga

Otsingu salvestamine

Trüki

INFO

Tooterühm

Väikeekskavaatorid 7t-12t

Mark / mudel

CAT 313

Tootmisaasta

2022

Töötunnid

700 h

Riik

Hiina

Üldine hinne

Mascus ID

007372FA

HIND

Vali valuuta

DETAILID

Varasemaid omanikke

Alusvankri seisukord

good

Täismass

13,000 kg

Heitmestandard

Stage V/Tier IV Final

Mootori võimsus

90 kW (122 hj)

Mootori tootja

japan

Kopa mahtuvus

0.65 m³

Roomiku laius

600 mm

Transpordimõõtmed (p x l x k)

761024902.83 m

Originaalvärv

YELLOW

Varre pikkus

960 mm

Seisukord/Garantii

good

Toodetud

Jaapan

Tarnetingimused

FOB, EXW

Sertifikaadid

EPA Sertifikaat, CE sertifikaat, ANSI sertifikaat, AS, CSA, EAC GOST, TRUA, JIS, TÜV, ASME

Lisad

All the auxiliary accessories can be provided for you. The above information is for reference only, and the specific details need to be confirmed with the factory.

Lisad

Automaatne/hüdrauliline kiirliitmik

Hüdraulika katkestuse kaitseventiil - poom/tõstuk

Hüdraulika katkestuse kaitseventiil - nool/varras

GPS

Näita veel

Muu teave

Here are the parameters of Caterpillar CAT313 excavator: - **General Parameters** - **Model**: CAT®313 GC - **Working Weight**: 12,400 kg - **Bucket Capacity**: 0.53 m³ (0.6 m³ is optional) - **Engine Parameters** - **Engine Model**: Cat C3.6 - **Rated Power - ISO 14396**: 74.4 kW - **Rated Power - ISO 9249**: 70.6 kW - **Rated Speed**: 2200 r/min - **Displacement**: 3.6 L - **Bore × Stroke**: 98 mm × 120 mm - **Emission Standard**: National IV - **Hydraulic System Parameters** - **Main System - Maximum Flow - Equipment**: 247 L/min - **Maximum Pressure - Equipment - Normal**: 35,000 kPa - **Maximum Pressure - Travel**: 35,000 kPa - **Maximum Pressure - Swing**: 26,000 kPa - **Swing System Parameters** - **Swing Speed**: 11.5 rpm - **Maximum Swing Torque**: 43 kN·m - **Dimensions and Working Ranges** - **Boom Reach**: 4.65 m - **Stick Reach**: 2.5 m - **Shipping Height**: 2780 mm (top of cab) - **Handrail Height**: 2820 mm - **Shipping Length**: 7630 mm - **Tail Swing Radius**: 2160 mm - **Counterweight Clearance**: 895 mm - **Ground Clearance**: 425 mm - **Track Length**: 3490 mm - **Distance between Center of Track Rollers**: 2780 mm - **Track Gauge**: 1990 mm - **Transport Width**: 2490 mm - **Maximum Digging Depth**: 5770 mm - **Maximum Reach at Ground Level**: 8210 mm - **Maximum Cutting Height**: 8530 mm - **Maximum Loading Height**: 6070 mm - **Minimum Loading Height**: 1980 mm - **Maximum Depth Cut for 2440 mm Level Bottom**: 5370 mm - **Maximum Vertical Wall Digging Depth**: 5040 mm - **Force Parameters** - **Bucket Digging Force - ISO**: 95.7 kN - **Stick Digging Force - ISO**: 68.2 kN - **Oil Capacity** - **Fuel Tank**: 237 L - **Hydraulic Tank**: 77 L - **Cooling System**: 11 L - **Engine Oil**: 11 L - **Final Drive**: 3 L per sideNäita veel
