Komatsu WA 380
Hind km-ta
Trüki
INFO
Tooterühm
Rataslaadurid
Mark / mudel
Komatsu WA 380
Tootmisaasta
2023
Töötunnid
700 h
Riik
Hiina
Üldine hinne
1
2
3
4
5
Mascus ID
F3E09405
HIND
Vali valuuta
DETAILID
Inventarinumber
1
Seerianumber
1
Jõuallika tüüp
Diisel
Viimane ülevaatus
2025-07-01
Varasemaid omanikke
1
Täismass
17,610 kg
Tõstevõime
5,000 kg
Registreerimisnumber
1
Kere tüüp
Jäik raam
Kabiini tüüp
Kinnine
Heitmestandard
Stage V
Mootor
Original
Kopa mahtuvus
3.30 m3
Mootori võimsus
142 kW (193 hj)
Mootori tootja
Original
Maksimaalne kiirus
34 km/h
Lisahüdraulika tootlikkus
138 l/min
Transpordimõõtmed (p x l x k)
8300 x 2780 x 3395 mm
Originaalvärv
Original Yellow
Seisukord/Garantii
Good Condition
Rehvide mark
Original
Esisilla rehvide jääk
98
Tagasilla rehvide jääk
2
Toodetud
Jaapan
Tarnetingimused
FCA, FOB, CIF, EXW
Sertifikaadid
EPA Sertifikaat, CE sertifikaat
Lisad
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL
Business hours,24 hours, holidays and Sundays
Address: Shanghai City, China
Contact: Jason
Whatsapp: +86 13675656717
Mobile:+86 13675656717
Wechat:13675656717
Packaging Details
1. Flat frame is more suitable for large construction equipment without disassembly.
2. Containers are the cheapest and fastest.
3. Bulk carriers are more suitable for large construction equipment.
4. Ro-ro shipment is fast and suitable for all kinds of machines.
You can choose any mode of transportation according to your needs.
Lisad
Kliimaseade
Lisahüdraulika
Õhu eelpuhasti
Sõelkopp
Massilüliti
Vilkur
diislil töötav soojapuhur
Juhtkang
Standard kaevekopp
lammutaja/FOPS kabiinipiire
Muu teave
Basic performance
Rated load capacity (tons) : 3 to 5 tons
Rated load capacity (kg) : 5000
The operating weight of the entire machine (kg) is 17,610
Bucket capacity (m³)3.3
Maximum unloading height (mm) : 2820
Unloading distance (mm) : 1245
Excavation force (lifting force) (kN)168
Engine
Engine model: Komatsu SAA6D107E-1
Rated power (kw/rpm) : 142/2100
Displacement (L)6.69
Cylinder diameter × stroke (mm)107×124
The cooling method is water cooling
Working form: Water-cooled four-stroke turbocharged direct injection type, intercooled, electronic speed regulation
Oil capacity
Fuel tank (L)300
Hydraulic oil tank (L)139
Engine oil (L)23
Coolant (L)30.5
Transmission
Transmission brand and model: single-stage, single-phase, 3-component
Maximum speed (km/h) : 34.0
Drive axle
The drive axle model is four-wheel drive
The drive axle swing Angle (°) is 80
Steering system
Steering Angle: 40
Turning radius - outer side of the bucket (mm)40
The minimum turning radius of the centerline of the outer wheel is 6320
Hydraulic system
The type of hydraulic pump is a piston pump
At the rated speed (l/min), the flow rate is 138
Rated working pressure (bars) : 31.4Mpa
The diameter of the boom cylinder × stroke (mm×mm) is 130*713
Bucket cylinder diameter × stroke (mm×mm)150*535
The operating time of the working device
Lift (s)5.9
Uninstall (s)1.8
Lower the empty bucket (s)3.3
Three items sum up (s)11
Technical parameters
Overturning load (kg) 14,790
The height of the material transportation position (mm) is 4095
Overall machine size
The overall length of the machine (mm) is 8300
The overall width of the machine (mm) is 2780
The overall height of the machine is 3395 mm
The maximum length of the entire machine (mm) is 7765
The maximum total height of the entire machine (mm) is 5195
Minimum ground clearance (mm) : 455
Bucket width (mm) : 2760
Wheelbase (mm) : 3300
Track (mm) : 2160
